14
49-2001160 Rev. 0
If you have questions, call 800.GE.CARES or visit our website at: GEAppliances.com.
Installation
Radiant Downdraft Cooktop
Instructions
PP9830
WARNING
%HIRUHEHJLQQLQJWKHLQVWDOODWLRQ
switch power off at the service panel and lock the
service disconnecting means to prevent power from
being switched on accidentally. When the service
disconnecting means cannot be locked, securely
fasten a prominent warning device, such as a tag,
to the service panel.
WARNING
To reduce the risk of fire, use only
metal ductwork.
BEFORE YOU BEGIN
Read these instructions completely and
carefully.
•
IMPORTANT –
Save these
instructions for local inspector’s use.
•
IMPORTANT –
Observe all governing
codes and ordinances.
•
IMPORTANT –
Remove all packing
and material and literature before connecting gas
and electrical supply to cooktop.
•
IMPORTANT –
To avoid damage to
your cabinets, check with your builder or cabinet
supplier to make sure that the materials used will
not discolor, delaminate or sustain other damage.
This product has been designed in accordance
ZLWKWKHUHTXLUHPHQWVRI8/DQG&6$,QWHUQDWLRQDO
and complies with the maximum allowable wood
cabinet temperatures of 194°F (90°C).
• Note to Installer – %HVXUHWROHDYHWKHVH
instructions with the Consumer.
• Note to Consumer – Keep these instructions for
future reference.
• Servicer – The electrical diagram is located inside
the cooktop.
• Proper installation is the responsibility of the
installer.
• Product failure due to improper installation is not
covered under the Warranty.
CUTTING THE COUNTERTOP
If you are installing the cooktop in a solid surface
material such as granite, quartz or any other natural
or synthetic solid surface, we recommend that the
cutout be prepared by a professional cabinet or
coutertop installer.
Cooktop cutouts in wood or wood -laminate
countertops may be able to be prepared using a
saber saw and electric drill.
MATERIALS YOU MAY NEED
‡ 'XFWWDSH
• Sheet metal screws
‡ 'XFWZRUNWRVXLWWKHDSSOLFDWLRQ
• Junction box
• Strain relief clamp for 1/2" trade size conduit
• Wire
nuts
TOOLS YOU WILL NEED
• Safety Glasses
• Saw
• Pencil
•
Measuring tape
or scale
• Carpenter’s square
• Electrician's Pliers
• Adjustable wrench
or socket set (
7 /
16
”
socket and ratchet)
• 'ULOODQGGULOOELW
• 1 /
4
” nut driver
• Flat blade screwdriver
INST
ALLA
TION INSTRUCTIONS
