OUTLINE OF THIS

CAMERA

Connect the DVI cable to the DVI OUT terminal of the rear panel.

Connect the DVI cable to the DVI IN terminal of the unit having a DVI
input terminal.

Connect the analog RGB cable to the RGB OUT terminal of the rear
panel.

Connect the analog RGB cable to the RGB IN terminal of the unit
having an analog RGB input terminal.

②

For Connecting to device having DVI Input Terminal

③

For Connecting to device having Analog RGB Input Terminal

Note:

• The display position of the screen may be displaced from the center of the screen. In this

case, adjust the horizontal and vertical positions manually from the connected device.

• Vertical stripes may appear on the LCD projector or the monitor screen. In this case, adjust the

dot clock manually from the connected device. The vertical stripes may be mitigated.

• When a laptop having an external output mode switching function is used, switch the video

output of the Camera to [PC] and then set the laptop to the external output mode.
