Elmo Document Camera P30S - Manual (Page 19)

98
ENGLISH
OUTLINE OF THIS
CAMERA
* : Factory setting
OSD Setting Menu
When the output video is switched to the camera video as per "Switching Video" (P.118) and
the [MENU/ENTER] button is pressed, the OSD Main menu appears.
When [
SETTINGS] is selected from the OSD Main menu, the OSD Setting menu appears.
Icon Name Condition Selection item Function
BRIGHTNESS －
AUTO
To vary the degree of auto-following brightness
automatically according to the brightness of the object.
MANUAL To fix the brightness of the video to any degree.
BRIGHTNESS
SETTING
BRIGHT
NESS
[AUTO] NORMAL
To reset the degree of brightness adjustment
to the initial settings.
ADJUST
To brighten the camera video with the [↑] level bar
and darken the camera video with the [↓] level bar.
BRIGHT
NESS
[MANUAL]
－
To brighten the camera video with the [↑] level bar
and darken the camera video with the [↓] level bar.
WHITE
BALANCE
－
AUTO To set the white balance to the auto following.
ONE-PUSH To set the white balance to the fix.
MANUAL
To set the white balance so that [R-GAIN] and
[B-GAIN] can be adjusted manually.
R-GAIN
WHITE
BALANCE
[MANUAL]
－
To adjust the red gain of the camera video
with the [↑] and [ ↓] level bars.
B-GAIN
WHITE
BALANCE
[MANUAL]
－
To adjust the blue gain of the camera video
with the [↑] and [ ↓] level bars.
TEXT
SETTING
－
TEXT1
To select the settings in the Text Mode.
The larger the number is, the stronger the
effect is.
TEXT2
TEXT3
EDGE
EFFECT
GRAPHICS
3
To enhance the outline of characters, etc. written
on the object to sharpen the video.
The larger the number is, the stronger the effect is.
2
1
OFF
Ń ł ń Ō
