Package Contents

Use the bolts supplied with this mount to install it, as directed in this manual. Do not substitute these bolts with any other

types. In addition, you need to use M8

× 50 mm anchors (at least 3 pcs.) and 8 × 80 mm lag bolts (at least 3 pcs.) that are

available at the store to attach the wall plate to the wall.

Gather the tools and parts you need before you begin installation.

Hexagon wrench (M4, M8)

Installation manual
(this manual)

Wall plate cover

Wall plate

Cable cover

Arm cover

M4

× 12 mm hexagon socket head

cap bolt
without washers (11 pcs.)

M4

× 12 mm hexagon socket head

cap bolt
with washers (2 pcs.)

M8

× 16 mm hexagon socket head

cap bolt
without washers (2 pcs.)

ELPMB24 Wall Mount

Projector plate
