Hardware Installation
17
4. Ensure that the fan assembly is aligned with the chassis vents according to
the fan assembly instruction.
5. Secure the motherboard with a minimum of eight-to-ten screws.
Connecting Cables and
Setting Switches
This section takes you through all the connections and switch settings necessary
on the motherboard. This will include:
‰ Power Connections
¾ 24-pin ATX power ( PWR1 )
¾ 8-pin ATX 12V power ( PWR2 )
¾ Auxiliary power for graphics ( PWR3 )
‰ Internal Headers
¾ Front panel
¾ IEEE 1394a
¾ USB Headers
¾ Audio
¾ Speaker
¾ COM
‰ FDD
‰ IDE
‰ Serial ATA II
‰ Chassis Fans
‰ Rear panel USB 2.0 Adapter
‰ Expansion slots
‰ CMOS jumper settings
See Figure 1 on page 11 to locate the connectors and jumpers referenced in the
following procedure.
