Installing and Configuring the EVGA nForce 680i SLI Motherboard
10
1394 Cable
Provides an additional 1394 ports to either the back
panel of the chassis.
USB 2.0 4-Port Cable
Provides four additional USB ports to either the front
or back panels of the chassis.
SATA Signal Cable (Qty Six)
Used to support the Serial ATA protocol and each one
connects a single drive to the motherboard
Comm2 Bracket Cable
IDE-ATA 133 HDD Cable
SLI Connector
Used to connect two graphic cards installed in the x16
PCI Express slots in an SLI configuration.
Chipset Fan
This fan is recommended for use if overclocking or
using liquid/passive cooling solution.
EVGA nForce 680i SLI
Motherboard
The EVGA nForce 680i SLI motherboard with the 680i SPP and MCP
processors is a PCI Express, SLI-ready motherboard. Figure 1 shows the
motherboard and Figures 2 shows the back panel connectors.
