Hardware Installation
FDD Connector
The motherboard supports a standard 360K, 720K, 1.2M, 1.44m, and a 2.88M
floppy disk drive (FDD).
Expansion Slots
The EVGA nForce 780i SLI motherboard contains six expansion slots, four
PCI Express slots and two PCI slots. For a full list of PCI Express x16 graphics
card supported by this motherboard, go to
www.nvidia.com/estore
.
PCI Slots
The two PCI slots support many expansion cards such as a LAN card, USB
card, SCSI card and other cards that comply with PCI specifications. When
installing a card into the PCI slot, be sure that it is fully seated. Secure the card’s
metal bracket to the chassis back panel with the screw used to hold the blank
cover.
1
1 – PCI slots
2 – PCIe x16 slots
(3-Way SLI)
3 – PCIe x1 slot
2 1
3 2 2
