Model 2: End-System Authorization
Enterasys NAC Design Guide 2-3
and information on the network. Enterasys NAC can be leveraged to provide information to
SIM solutions, by mapping an IP address to an identity, such as a MAC address or username
and location, for a more complete representation of the attack source or target on the network.
In this way, the Enterasys NAC solution further enhances the operation of existing security
technologies deployed on the network.
Required and Optional Components
This section summarizes the required and optional components for Model 1.
.
The NAC Gateway and NAC Controller are the NAC appliances used to implement the out‐of‐
band and inline network access control functionality on the network.
NetSight NAC Manager is the software application used to centrally manage the NAC appliances
deployed on the network.
NetSight Console is the software application used to monitor the health and status of
infrastructure devices in the network, including switches, routers, and Enterasys NAC appliances
(NAC Gateways and NAC Controllers).
Assessment functionality is optional because in this deployment model, end‐systems are not being
assessed for security posture compliance when connecting to the network.
A RADIUS server is only required if out‐of‐band network access control using the NAC Gateway,
or inline network access control using the Layer 2 NAC Controller, is implemented with web‐
based and/or 802.1X authentication.
NetSight Policy Manager is not required because additional policies and authorization levels do
not need to be defined for this deployment model.
NetSight Inventory Manager is an optional component, providing comprehensive network
inventory and change management capabilities.
Model 2: End-System Authorization
This NAC deployment model implements the detection, authentication, and authorization of
connecting end‐systems, to control access to network resources based on user and end‐system
identity, as well as location. In Model 1, end‐systems and end users are detected and tracked on
the network over time. This gives IT operations visibility into what devices are connected to the
network, who is using these devices, and where these devices are connected. In model 2, the
Table 2-1 Component Requirements for Detection and Tracking
Component
Detection and
Tracking
NAC Appliance Required
NetSight NAC Manager Required
NetSight Console Required
Assessment Optional
RADIUS Server Optional
NetSight Policy Manager Optional
NetSight Inventory Manager Optional
