Enterasys NAC Design Guide 2-1
2
NAC Deployment Models
This chapter describes the four NAC deployment models and how they build on each other to
provide a complete NAC solution. The first model implements a subset of the five key NAC
functions (as described in
Chapter 1 ), and each subsequent model provides additional
functionality without the need to replace existing pieces of the NAC solution. This allows
businesses who are still in the early stages of NAC deployment, to take a phased approach to
implementing NAC while deriving value from the solution at each step along the way.
Model 1: End-System Detection and Tracking
This NAC deployment model implements the first key NAC function, detection. The detection of
connecting end‐systems provides the network administrator with visibility into what devices are
connecting to the network, who is using these devices, and where the devices are connected.
For many NAC deployments, the first phase consists of tracking over time the end‐systems and
end users connected to the network, in order to profile and enumerate the assets on the enterprise
network. It is important to note that in this model, the NAC solution does not play a part in
authorizing access for connecting end‐systems, leaving this to the default configurations on the
switch. The end‐systems connect to the network and are allocated “business‐as‐usual” access to
network resources, while the NAC solution provides visibility into the connection behavior and
details of these devices.
Implementation
End‐systems can be detected and tracked in different ways depending on whether inline or out‐of‐
band network access control is implemented.
Out-of-Band NAC
For out‐of‐band NAC utilizing the NAC Gateway appliance, detection is implemented as follows.
In the case of web‐based or 802.1X authentication, end‐systems are detected with the receipt of
RADIUS packets from an access edge switch attempting to authenticate an end‐system. The
For information about... Refer to page...
Model 1: End-System Detection and Tracking 2-1
Model 2: End-System Authorization 2-3
Model 3: End-System Authorization with Assessment 2-8
Model 4: End-System Authorization with Assessment and Remediation 2-12
Summary 2-16
