NAC Solution Components
1-4 Overview
NAC Solution Components
This section discusses the required and optional components of the Enterasys NAC solution,
beginning with the following table that summarizes the component requirements for each of the
four deployment models.
.
The NAC Appliance
The NAC appliance is a core component of the Enterasys NAC solution and is required for all
NAC deployment models. It provides the ability to detect, authenticate, and effect the
authorization of end devices attempting to connect to the network. It also integrates with or
connects to assessment services to determine the security posture of end‐systems connecting to
the network. Once authentication and assessment are complete, the NAC appliance effects the
authorization of devices on the network by allocating the appropriate network resources to the
end‐system based on authentication and/or assessment results.
If authentication fails and/or the assessment results indicate a noncompliant end‐system, the NAC
appliance can deny the end‐system access to the network, quarantine the end‐system with a
highly restrictive set of network resources, or permit network access, depending on the appliance’s
configuration.
The NAC appliance also provides the remediation functionality by means of a Remediation Web
Server that runs on the appliance. Remediation informs end users when their end‐systems have
been quarantined due to network security policy non‐compliance, and allows end users to safely
remediate their end‐systems without assistance from IT operations.
Table 1-1 Component Requirements for NAC Deployment Models
NAC Component
Model 1
Detection and
Tracking
Model 2
Authorization
Model 3
Authorization with
Assessment
Model 4
Authorization with
Assessment and
Remediation
NAC Appliance Required Required Required Required
NetSight NAC
Manager Required Required Required Required
NetSight Console Required Required Required Required
Assessment Server Optional Optional Required Required
RADIUS Server 1 Optional Optional Optional Optional
NetSight Policy
Manager
2
Optional Optional Optional Optional
NetSight Inventory
Manager
3
Optional Optional Optional Optional
1. A RADIUS server is only required if out-of-band NAC is implemented with the NAC Gateway, and
802.1X or web-based authentication is deployed on the network.
2. NetSight Policy Manager is required for inline NAC deployments. NetSight Policy Manager is
suggested if Enterasys policy-capable switches are deployed on the network and utilized as the
traffic enforcement or authorization point for connecting devices. Policy Manager allows the
centralized definition and deployment of policies to Enterasys switches for the consistency and
ease of management of the authorization levels for connecting end-systems.
3. NetSight Inventory Manager is suggested if Enterasys switches are deployed on the network for
ease of firmware and configuration management across the enterprise.
