Site Pla
n
n
in
g
Da
ta
, 10
00kV
A, Sin
g
le-Mod
u
le Sys
te
m
s
44
Table 6 Site planning data—600V input
UPS
Rating
AC Output
Voltage Options
Bypass AC
Input Current
Rectifier AC
Input Current
Inverter or
Bypass AC
Output Current Required
Battery
Disconnect
Rating (A)
Max. Battery
Current
at End of
Discharge (A)
% Efficiency
at Full Load
Max. Heat
Dissipation
Full Load
BTU/h (kWH)
Dimensions
Approx.
Weight
Unpacked
Floor
Loading
Distributed
Loading
kVA kW VAC
Input
Filter Nom Nom Max Nom Max
WxDxH:
in. (mm) lb. (kg) lb./ft. 2 (kg/m 2 )
1000 900 600 No 962 1096 * 1369 962 1203 2500 2440 93 231,203 (67.7)
177x44x82
(4496x1118x2083)
16700 (7575) 309 (1509)
1000 900 600 Yes 962 1012 ** 1265 962 1203 2500 2440 93 231,203 (67.7) 17550 (7961) 325 (1587)
See Notes (p. 43): 13 3,5,7,8,9,11,12 1,4,5,7,8,9,11,12 2,5,7,8,9,11,12 6 6,8,9,11,12 — — 14 14 —
* Nominal Input Power Factor 0.85 lagging at full load; 9% Maximum Total Input Harmonic Current Distortion (THD) at full load.
** Nominal Input Power Factor 0.92 lagging at full load; 4% Maximum Total Input Harmonic Current Distortion (THD) at full load.
Table 7 Site planning data—480V input
UPS
Rating
AC Output
Voltage Options
Bypass AC
Input Current
Rectifier AC
Input Current
Inverter or
Bypass AC
Output Current Required
Battery
Disconnect
Rating (A)
Max. Battery
Current
at End of
Discharge (A)
% Efficiency
at Full Load
Max. Heat
Dissipation
Full Load
BTU/h (kWH)
Dimensions
Approx.
Weight
Unpacked
Floor
Loading
Distributed
Loading
kVA kW VAC
Input
Filter Nom Nom Max Nom Max
WxDxH:
in. (mm) lb. (kg) lb./ft. 2 (kg/m 2 )
1000 900 480 No 1203 1369 * 1712 1203 1504 2500 2440 93 231,203 (67.7)
177x44x82
(4496x1118x2083)
16700 (7575) 309 (1509)
1000 900 480 Yes 1203 1125 ** 1582 1203 1504 2500 2440 93 231,203 (67.7) 17550 (7961) 325 (1587)
See Notes (p. 43): 13 3,5,7,8,9,11,12 1,4,5,7,8,9,11,12 2,5,7,8,9,11,12 6 6,8,9,11,12 — — 14 14 —
* Nominal Input Power Factor 0.85 lagging at full load; 9% Maximum Total Input Harmonic Current Distortion (THD) at full load.
** Nominal Input Power Factor 0.92 lagging at full load; 4% Maximum Total Input Harmonic Current Distortion (THD) at full load.
