Tascam MZ-123BT Multi-Zone Audio Mixer with Bluetooth User Manual
Page 6
6
TASCAM MZ-123BT
Introduction
Thank you very much for purchasing the TASCAM MZ-123BT.
Before using this unit, read this Owner’s Manual carefully so that
you will be able to use it correctly and enjoy working with it for
many years. After you have finished reading this manual, please
keep it in a safe place for future reference.
You can also download this Owner’s Manual from the TEAC
Global Site (http://teac-global.com/).
Features
p
Rackmount mixer that enables assignment of background
music and mic announcements to three zones
p
Provides convenient background music playback setup
o
Built-in Bluetooth® receiver enables music input from
smartphones, tablets and other devices
o
Built-in AUX input enables music input from portable
music players and other devices that do not support
Bluetooth®
p
Necessary controls for daily use have been carefully selected
and placed on the front, making operation also easy for
endusers
p
The Bluetooth® antenna on the front makes stable Bluetooth®
connection possible even in environments with many
obstacles
p
Different input sources can be assigned to each of the three
sets of outputs
o
Each output has a mono/stereo switch
1
o
Euroblock terminals are ideal for permanent installations
p
Three sets of line input channels
o
Channel 1: line input (RCA, unbalanced)
o
Channel 2: line input (RCA, unbalanced)
o
Channel 3: AUX input/Bluetooth®
2
p
Two mic input channels ideal for announcements
o
Mic 1 can be connected to the XLR/TRS combo jack on
the front or the Euroblock terminal for installed use on the
back
o
Talkover function automatically lowers background music
volume according to mic volume
o
Flexible audio tone adjustment is possible using the
3-band equalizer and high-pass filter
o
+48V phantom power supported
p
Headphone jack can be used to monitor every output
p
Compact 1U rackmount size
1 When mono output is selected, a stereo input source will
be output as a mono mix.
2 During operation, select AUX input or a Bluetooth® source.
Contents
IMPORTANT SAFETY INSTRUCTIONS ..................................... 3
Wireless equipment precautions ........................................... 5
Introduction ............................................................................. 6
Features .................................................................................... 6
Included items ......................................................................... 7
Conventions used in this manual ........................................... 7
Precautions for placement and use ........................................ 7
Notes about power supply ...................................................... 7
Beware of condensation ......................................................... 7
Cleaning the unit ..................................................................... 7
Bluetooth® ................................................................................ 7
Profiles .........................................................................................................7
Codecs .........................................................................................................7
Content protection .................................................................................8
Transmission security .............................................................................8
Using the TEAC Global Site ..................................................... 8
Product registration ................................................................ 8
About TASCAM customer support service ............................. 8
Names of parts ......................................................................... 9
Front panel .................................................................................................9
Rear panel ................................................................................................ 11
Preparation ............................................................................ 12
Connecting other equipment ............................................... 13
jack ............................................................................................................. 15
Output channels ................................................................................... 16
Using the talkover function .............................................................. 16
Monitoring .............................................................................................. 16
Troubleshooting .................................................................... 16
Specifications ......................................................................... 17
Audio inputs ........................................................................................... 17
Audio outputs ........................................................................................ 17
Audio performance .............................................................................. 18
Bluetooth ................................................................................................. 18
Other ......................................................................................................... 18
