HP Z34C G3 34" 21:9 Curved WQHD IPS Monitor - Manual (Page 13)

IMPORTANT: Before you disassemble the monitor, be sure that the monitor is turned off and all cables are
disconnected.
IMPORTANT: To position and stabilize the monitor, HP recommends that two people perform these
procedures.
1. Disconnect and remove all cables from the monitor.
2. Position the monitor upside down on a flat surface covered by protective sheet made of foam or a clean,
dry cloth.
3. Push up the latch near the bottom center of the stand’s mounting plate (1).
4. Swing the bottom of the stand up until the mounting plate clears the recess in the monitor head (2).
5. Slide the stand out of the recess.
Attaching the monitor head to a mounting device
You might need additional tools such as a screwdriver (purchased separately) when you attach a mounting
device. To avoid damage to your monitor, follow these instructions.
8 Chapter 1 Getting started
