Liquid crystal display (LCD) with active matrix and in-plane switching (IPS)
●
Wide color gamut to provide coverage of the P3 color space
●
Nonglare panel with an LED backlight
●
Wide viewing angle to allow viewing from a sitting or standing position, or moving from side to side
●
Tilt, swivel, and height adjustment capabilities
●
Pivot capability to rotate the monitor head from landscape to portrait orientation
●
Dual Picture in Picture (PIP) and Picture beside Picture (PbP) functionality to enable the DisplayPort™
and High-Definition Multimedia Interface™ (HDMI) inputs to be viewed in each half of the screen
●
On-screen display (OSD) adjustments in several languages for easy setup and screen optimization
●
Workflow-based color space presets for standard and wide gamut applications
●
Energy saver feature to meet requirements for reduced power consumption
●
Security cable slot on the rear of the monitor for an optional security cable
●
Cable management feature for placement of cables and cords
Connectors
●
DisplayPort 1.4 video input (cable included)
●
DisplayPort 1.4 downstream pass through connection
●
High-Definition Multimedia Interface™ (HDMI) video input (cable included)
●
USB Type-C® port (DisplayPort Alt Mode 1.4, power delivery up to 100 W, cable included)
●
USB Type-C port (data only, power delivery up to 15 W, downstream)
●
Three USB ports that connect to USB devices (downstream)
●
USB Type-C-to-USB Type-A cable provided
●
USB Type-C-to-USB Type-C cable provided
●
Plug and Play capability, if supported by your operating system
Monitor stand
●
Removable stand for flexible monitor head mounting solutions
●
HP Quick Release 2 device to quickly attach the monitor head to the stand with a simple click, and then
remove it with the convenient sliding tab release
●
VESA® mounting bracket for attaching the monitor head to a wall-mount device or swing arm
●
VESA mounting capability (100 × 100 mm) for attaching the monitor to a swing arm mount
●
Support for a mounting bracket to attach the monitor to a workstation
NOTE:
For safety and regulatory information, see the Product Notices provided in your documentation kit.
To access the latest user guide, go to
ollow the instructions to find your
product. Then select Manuals.
Front components
To identify the components on the front of the monitor, use this illustration and table.
