Extron Electronics RGB 201 - Manual (Page 36)

RGB 201 R
xi Universal Interface • Remote Contr
ol
Remote Contr
ol, cont’d
3-4
Command/response table for SIS commands
Command ASCII Command Response Additional description
(host to switcher) (switcher to host)
Horizontal shift
Set horizontal shift
X@
H Hph
X@]
Set horizontal shift value to
X@
(range -127 to +127).
Example : 28H Hph+028
]
Set horizontal shift value to +28.
Increment horizontal shift value +H Hph
X@]
Previous horizontal shift value +1 (shift right).
Decrement horizontal shift value -H Hph
X@]
Previous horizontal shift value -1 (shift left).
View horizontal shift value H
X@]
Vertical shift
Set vertical shift
X@
/ Vph
X@
Set vertical shift value to
X@
(range -127 to +127).
Example : -5/ Vph-005
]
Set horizontal shift value to -5.
Increment vertical shift value +/ Vph
X@]
Previous vertical shift value +1 (shift up).
Decrement vertical shift value -/ Vph
X@]
Previous vertical shift value -1 (shift down).
View vertical shift value /
X@]
View, information, part number, and firmware requests
Information request I/i Hph
X@
•Vph
X@
•Hrt
X$
•Vr
X$]
Example Hph+028•Vph-005•Hrt48.400•Vrt60.000
]
Horizontal shift value +28; vertical shift value -5;
horizontal rate 48.4 kHz; vertical rate 60 Hz.
Request for part number N/n
X^]
Example: n 60-507-01
]
60-507-01 = RGB 201 Rxi.
Query software version Q/q
X#]
Example: q 1.23
]
Software version 1.23 (example only).
