FW-85BZ40H / 75BZ40H / 65BZ40H / 55BZ40H
5-014-879- 11 (1)
6 US
Connection Diagram
5 V
500 mA MAX
1 2
5 V
900 mA MAX
USB USB
(OPTICAL)
DIGITAL AUDIO OUT
VIDEO IN
VIDEO/
AUDIO L-R
LAN
REMOTE
RS-232C
HDMI 4
AUDIO IN
1
2
3
4
IN
(ARC)
(DVI)
USB storage
media/Keyboard/
Mouse etc.
Audio System
with Optical
Audio Input
VCR/Video game
equipment/DVD
player/Camcorder
Headphone
HDMI Device/PC
Audio System
with ARC/HDMI
Device
DVI-HDMI
Adapter/HDMI
Device/PC
Router
Home Controller
DVI-Audio Out
HDMI Device/PC
