FW-85BZ40H / 75BZ40H / 65BZ40H / 55BZ40H
5-014-879- 11 (1)
19 US
LAN
10BASE-T/100BASE-TX connector
(Depending on the operating
environment of the network, connection
speed may differ. The communication
rate and quality are not guaranteed.)
REMOTE
RS-232C mini jack
These jacks are for receiving the external
control signal.
Power and others
Power requirements
110 V – 240 V AC, 50/60 Hz (U.S.A./
Canada 120 V AC, 60 Hz)
Power consumption
In use
FW-85BZ40H: 318 W
FW-75BZ40H: 277 W
FW-65BZ40H: 214 W
FW-55BZ40H: 173 W
In standby*
4
*
5
Less than 0.5 W with 120 V AC and less
than 0.5 W with 240 V AC
Screen size (measured diagonally) (Approx.)
FW-85BZ40H: 214.8 cm / 84.6 inches (85”
class)
FW-75BZ40H: 189.3 cm / 74.5 inches (75”
class)
FW-65BZ40H: 163.9 cm / 64.5 inches (65”
class)
FW-55BZ40H: 138.8 cm / 54.6 inches (55”
class)
Display resolution
3,840 dots (horizontal) × 2,160 lines
(vertical)
Output Rating
USB 1
5 V , 500 mA MAX
USB 2
5 V , 900 mA MAX
Dimensions (Approx.) (w × h × d) (mm) /
(inches)
with stand (without stand)
FW-85BZ40H: 1,899 Ч 1,162 Ч 441 / 74
7
/
8
Ч
45
3
/
4
Ч 17
3
/
8
(1,899 Ч 1,089 Ч 72 / 74
7
/
8
Ч
42
7
/
8
Ч 2
7
/
8
)
FW-75BZ40H: 1,674 Ч 1,034 Ч 410 / 66 Ч 40
3
/
4
Ч 16
1
/
4
(1,674 Ч 961 Ч 71 / 66 Ч 37
7
/
8
Ч
2
7
/
8
)
FW-65BZ40H: 1,450 Ч 903 Ч 338 / 57
1
/
8
Ч
35
5
/
8
Ч 13
3
/
8
(1,450 Ч 833 Ч 70 / 57
1
/
8
Ч
32
7
/
8
Ч 2
7
/
8
)
FW-55BZ40H: 1,231 Ч 780 Ч 338 / 48
1
/
2
Ч
30
3
/
4
Ч 13
3
/
8
(1,231 Ч 710 Ч 70 / 48
1
/
2
Ч
28 Ч 2
7
/
8
)
wall-mount hole pattern
FW-85BZ40H: 400 × 400 mm
FW-75BZ40H: 300 × 300 mm
FW-65BZ40H: 300 × 300 mm
FW-55BZ40H: 300 × 300 mm
wall-mount screw size (mm)
M6 (length: see “Installing the LCD
Display to the Wall”.)
Mass (Approx.) (kg) / (lb.)
with stand (without stand)
FW-85BZ40H: 47.7 / 105.1 (45.8 / 100.9)
FW-75BZ40H: 34.4 / 75.8 (32.9 / 72.5)
FW-65BZ40H: 23.2 / 51.2 (22.2 / 48.9)
FW-55BZ40H: 17.5 / 38.6 (16.5 / 36.4)
Others
Optional accessories
Wall-Mount Bracket: SU-WL855
(FW-75BZ40H / 65BZ40H / 55BZ40H only)
Wall-Mount Bracket: SU-WL500
Camera and Microphone Unit: FWA-CE100
Operating temperature: 0 ºC – 40 ºC /
32 ºF – 104 ºF
*1 When 4096 × 2160p is input and [Wide mode]
is set to [Normal], the resolution is displayed as
3840 × 2160p. To display 4096 × 2160p, set
[Wide mode] setting to [Full 1] or [Full 2].
*2 To support 18 Gbps, set [HDMI signal format] to
[Enhanced format].
*3 Connect your audio system to the HDMI IN 3 to
route LCD Display audio to your audio system.
*4 Specified standby power is reached after the
LCD Display finishes necessary internal
processes.
*5 Standby power consumption will increase
when your LCD Display is connected to the
network.
Note
• Optional accessories availability depends on
countries/region/LCD Display model/stock.
• Design and specifications are subject to change
without notice.
• Some of the on-screen instructions may not
apply to your LCD Display model.
