Table of Contents
Connection Diagram . . . . . . . . . . . . . .6
Remote Control and LCD Display . . . .8
Settings . . . . . . . . . . . . . . . . . . . . . . . . .9
Pro mode. . . . . . . . . . . . . . . . . . . . . . . . . 9
Recommended settings. . . . . . . . . . . . 10
Control functions . . . . . . . . . . . . . . . . 11
RS-232C . . . . . . . . . . . . . . . . . . . . . . . . . 11
IP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Appendix . . . . . . . . . . . . . . . . . . . . . . 14
Extended software . . . . . . . . . . . . . . . . 14
the Wall . . . . . . . . . . . . . . . . . . . . . . . . 15
Troubleshooting . . . . . . . . . . . . . . . . . 18
Specifications . . . . . . . . . . . . . . . . . . . 18
Note
• Images and illustrations used in the Setup Guide and this
manual are for reference only and may differ from the
actual product.
• This LCD Display displays all video input signals in a
resolution of 3,840 dots × 2,160 lines.
Location of the identification label
Labels for the LCD Display Model No. and Power Supply
rating are located on the rear of the LCD Display.
IMPORTANT NOTICE
IMPORTANT NOTICE TO MEXICO
This equipment operation is subject to the following two
conditions: (1) It is possible that this equipment or device
may not cause harmful interference, and (2) this equipment
or device must accept any interference, including
interference that may cause undesired operation.
For information related to certificate number, refer to the
package label and/or product.
Note: This product uses the following module for wireless
functionalities:
Model: DHUR-SY63
Brand: Wistron NeWeb Corporation
For models with supplied plug adapter:
This plug adapter is not for the use in Chile, Paraguay and
Uruguay. Please use this plug adapter in the countries
where it is necessary.
CAUTION
To prevent electric shock and blade exposure, do not use
this AC plug with an extension cord, receptacle or other
outlet unless the blades can be fully inserted.
• Operate the LCD Display only on 110 V – 240 V AC (U.S.A./
Canada 120 V AC)
Safety Information
Notice for customers in the United States
of America
About Manuals
This LCD Display comes with the following
manuals. Please retain the manuals for
future reference.
Setup Guide
• LCD Display
installation and
setup.
Reference Guide (this
manual) / Safety
Documentation
• Safety information,
remote control, troubleshooting,
wall-mount installation, specification,
etc.
Help
Find more troubleshooting and
other useful information
directly from your LCD Display.
Press
HELP
on the remote
control to display a list of
topics.
IMPORTANT - Read the End User Software License
Agreement before using your Sony product.
Using your
product indicates your acceptance of the End User
Software License Agreement. The software license
agreement between you and Sony is available online at
Sony website (http://www.sony.net/
tv-software-licenses/) or on your product screen. Go to
[Settings]
t
[Device Preferences]
t
[About]
t
[Legal
information]
t
[End user license agreement].
The 85” class has a 84.6 inch (214.8 cm) viewable image
size, the 75” class has a 74.5 inch (189.3 cm) viewable
image size, the 65” class has a 64.5 inch (163.9 cm)
viewable image size and the 55” class has a 54.6 inch
(138.8 cm) viewable image size (measured diagonally).
Supplier’s Declaration of Conformity
Trade Name: SONY
Model: FW-85BZ40H / FW-75BZ40H / FW-65BZ40H /
FW-55BZ40H
Responsible Party: Sony Electronics Inc.
Address: 16535 Via Esprillo, San Diego, CA 92127 U.S.A.
Telephone Number: 858-942-2230
