FW-85BZ40H / 75BZ40H / 65BZ40H / 55BZ40H
5-014-879- 11 (1)
12 US
(b) Responses from the LCD Display to the controller
Examples of RS-232C communication command are explained below.
For more details on RS-232C, please contact your sales representative.
You can control the LCD Display via IP from an HTML5/Android application on the LCD Display
or on the external device. You can manage and monitor information of input/power, start and
terminate applications, control the display such as input source and volume. You can also
restrict commands by the authentication function.
When using [IP control], set the LCD Display as follows first.
Go to [Settings]
t [Network & Internet] t [Home network] t [IP control].
• Set [Authentication] to [Normal and Pre-Shared Key].
• Set [Pre-Shared Key].
No. Item Value
1 Header 0x70 Answer
2 Answer 0x00 Completed (Normal End)
0x01 : Limit Over
(Abnormal End-Exceed maximum value)
0x02 : Limit Over
(Abnormal End-Exceed minimum value)
0x03 : Command Canceled (Abnormal end)
0x04 : Parse Error (Data Format Error)
3 Check Sum 0xXX
Command example
Control Head Category Function Length Data 1 Data X Checksum
Power
on/off
0x8C 0x00 0x00 0x02
0x00 (off) - 0x8E
0x01 (on) - 0x8F
HDMI
input
selection
0x8C 0x00 0x02 0x03
0x04
(HDMI)
0x01 (#1) 0x96
0x02 (#2) 0x97
0x03 (#3) 0x98
0x04 (#4) 0x99
IP
Supported IP protocol
Protocol name Layer Format Authentication Explanation
Web API HTTP JSON-RPC Yes The APIs whose purpose is device
control.
IRCCIP HTTP SOAP Yes Infrared Compatible Control over
Internet Protocol.
The technology and formats to
transmit remote control
commands via the Internet.
SSIP TCP Byte stream N/A Only typical functions are
supported.
LCD Display settings
