Installing and Configuring the EVGA nForce 680i SLI Motherboard
64
System Monitor Menu
Select
System Monitor
from the CMOS Setup Utility menu and press Enter to
display the System Monitor menu.
Figure 16. System Monitor Menu
All of the values shown in
Blue
are dynamic and change as the speed and
voltages of the various components change with system usage.
:Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5: Previous Values F7:Defaults
` Dynamic Fan Control [ Press Enter ]
CPU 47ºC/ 117ºF
Board 51ºC/ 124ºF
MCP 45ºC/ 113ºF
CPU Core 1.28V
CPU FSB 1.19V
Memory 1.81V
+3.3V 3.16V
+3.3V Dual 3/16V
+12V 11.92V
+5V 4.99V
+Vbat 3.00V
CPU Fan Speed 4272 RPM
MCP Fan Speed 4891 RPM
SPP Fan Speed 0 RPM
Mem Fan Speed 0 RPM
Sys Fan Speed 0 RPM
Item Help
Main Level
`
Phoenix – AwardBIOS CMOS Setup Utility
System Monitor
