Diagnostics and Troubleshooting MNET ♦ ProLinx Gateway
Driver Manual Modbus TCP/IP Interface Module
Page 44 of 78 ProSoft Technology, Inc.
September 1, 2010
Press [+] from the Database View menu to skip five pages ahead in the database
to see the 100 registers of data starting 500 registers after the currently displayed
page.
Moving Forward Through 5 Pages of Registers
Press [P] from the Database View menu to display the previous 100 registers of
data.
Viewing the Previous 100 Registers of Data
Press [N] from the Database View menu to display the next 100 registers of data.
Viewing the Next 100 Registers of Data
Press [D] from the Database View menu to display the data on the current page
in decimal format.
Viewing Data in Decimal Format
Press [H] from the Database View menu to display the data on the current page
in hexadecimal format.
Viewing Data in Hexadecimal Format
Press [F] from the Database View menu to display the data on the current page
in floating-point format. The program assumes that the values are aligned on
even register boundaries. If floating-point values are not aligned as such, they
are not displayed properly.
Viewing Data in Floating-Point Format
Press [A] from the Database View menu to display the data on the current page
in ASCII format. This is useful for regions of the database that contain ASCII
data.
Viewing Data in ASCII (Text) Format
Press [M] to return to the Main menu.
Returning to the Main Menu
