MVI71-GEC ♦ PLC 5 Platform Diagnostics and Troubleshooting
Generic ASCII Ethernet Communication Module User Manual
ProSoft Technology, Inc. Page 33 of 86
May 11, 2011
4 Diagnostics and Troubleshooting
In This Chapter
LED Status Indicators ............................................................................ 34
Using ProSoft Configuration Builder (PCB) for Diagnostics................... 36
Reading Status Data from the Module .................................................. 43
The module provides information on diagnostics and troubleshooting in the
following forms:
LED status indicators on the front of the module provide general information
on the module's status.
Status data contained in the module can be viewed through the
Configuration/Debug port, using the troubleshooting and diagnostic
capabilities of ProSoft Configuration Builder (PCB).
Status data values can be transferred from the module to processor memory
and can be monitored there manually or by customer-created logic.
