MVI71-MNET ♦ PLC Platform
Reference
Modbus TCP/IP Interface Module
User Manual
Page 74 of 109
ProSoft Technology, Inc.
June 23, 2009
Offset Description
Length
50
0
1
51 9959
1
52
Number of word registers in Modbus data set
1
53
Starting word address for Modbus data set
1
54 to 83
Modbus data set
30
84 to 113
Bit mask to use with the data set. Each bit to be considered
with the data set will have a value of 1 in the mask. Bits to
ignore in the data set will have a value of 0 in the mask.
30
Offset Description
Length
50
0
1
51 9970
1
52
1
1
53 0
1
The ladder logic should copy and parse the received message and control the
processor as expected by the master device. The processor must respond to the
formatted pass-through control blocks with a write block. The following tables
describe the format of the write blocks.
Offset Description
Length
50
9956, 9957, 9958, 9960 or 9961
1
Offset Description
Length
50
9956, 9957, 9958, 9960 or 9961
1
Offset Description
Length
50
9970
1
