Ladder Logic
MVI69-103M ♦ CompactLogix or MicroLogix Platform
IEC 60870-5-103 Master Communication Module
ProSoft Technology, Inc.
Page 47 of 131
November 3, 2008
Block Transfer Size = 60
Field Recommended
Value
Slot
The slot number in the rack where the module is installed
Input Assembly Instance
101
Input Size
62
Output Assembly Instance
100
Output Size
61
Configuration Assembly Instance
102
Configuration Size
0
Block Transfer Size = 120
Field Recommended
Value
Type
1769-MODULE Generic 1769 Module
Parent Local
Name MVI69
Description
MVI69 Application Module
Comm Format
Data - INT
Slot
The slot number in the rack where the module is installed
Input Assembly Instance
101
Input Size
122
Output Assembly Instance
100
Output Size
121
Configuration Assembly Instance
102
Configuration Size
0
Block Transfer Size = 240
Field Recommended
Value
Type
1769-MODULE Generic 1769 Module
Parent Local
Name MVI69
Description
MVI69 Application Module
Comm Format
Data - INT
Slot
The slot number in the rack where the module is installed
Input Assembly Instance
101
Input Size
242
Output Assembly Instance
100
Output Size
241
Configuration Assembly Instance
102
Configuration Size
0
