47
Item Description
KEY TONE Enable/ Disable keystrokes.
Relay Switch
Connection Set relay signal to be Normal Close (N.C.) or Normal
Open (N.O.).
Buzzer Duration Set up the duration from 1~999 seconds.
ALARM BUZZER
Enable/ Disable buzzer operation when the alarm is
triggered for sensor, motion and vloss (Video Loss).
ALARM RELAY
Enable/ Disable the signal to be sent to the RELAY
OUT blocks when the alarm is triggered for sensor,
motion and vloss (Video Loss).
5.9.4 Spot Setup
The DVR has two modes of video output; one is the main video output, the other
is spot video output. SPOT setup is for controlling orders of channels that the
system cycles through in SPOT mode. User can monitor every channel in the
SPOT mode.
Item Description
Auto-Seq. Interval
(Seconds) The duration interval time between channels is in
seconds under SPOT mode (1~999 seconds).
Skip Video Loss
Channel
Whether to skip channels without video signal.
Channels
Select which channels will be displayed in the
sequence.
