PLANET GSW-1200S 10
Figure 2-3 Attaching the brackets to the GSW-1200S
Caution:
You must use the screws supplied with the mounting brackets.
Damage caused to the parts by using incorrect screws would
invalidate your warranty.
Step3: Secure the brackets tightly.
Step4: Follow the same steps to attach the second bracket to the
opposite side.
Step5: After the brackets are attached to the switch, use suitable screws
to securely attach the brackets to the rack, as shown in Figure
2-4
Figure 2-4 Mounting the Switch in a Rack
Step6: Proceed with the steps 4 and steps 5 of session 2.2.1 Desktop
or Shelf Mounting to connect the network cabling and supply
power to your switch.
