USE ONLY MANUFACTURER'S REPLACEMENT PARTS. USE OF ANY OTHER PARTS COULD CAUSE INJURY OR
DEATH.
NOTE: SEE LOG INSTRUCTION MANUAL FOR DETAILS ON LOGS AND EMBERS
ATTENTION: When ordering parts, it is very important that part number and description of part coincide.
pARTS LIST
INDEX
NUMBER
pART NUMBER
DESCRIpTION
vfp36Sp32EN vfp36Sp32Ep vfp36pp32EN vfp36pp32Ep
1 17301 17301 17301 17301 TOP STANDOFF
2 R3491 R3491 R3491 R3491 COVER, JUNCTION BOX
3 R3492 R3492 R3492 R3492 RECEPTACLE, 3 PRONG
4 R9719 R9719 R9719 R9719 BRICK LINER
5 19401 19401 19401 19401 BRICK LINER BRACKET - LOWER
6 19945 19945 19945 19945 BRICK LINER BRACKET
7 24115 24115 24115 24115 JUNCTION BOX SUB-ASSEMBLY
8 18807 18807 18807 18807 LOUVER ASSEMBLY-UPPER
9 18808 18808 18808 18808 LOUVER ASSEMBLY-LOWER
10 N/A N/A 24059 24059 LOUVER ASSEMBLY-UPPER END
11 N/A N/A 24058 24058 LOUVER ASSEMBLY-LOWER END
12 20020 20020 20145 20145 HOOD
13 N/A N/A 24056 24056 HOOD - PENINSULA
14 20143 20143 20143 20143 FRONT FRAME ASSEMBLY
15 N/A N/A 24149 24149 SCREEN FRAME ASSEMBLY - END
16 10554 10554 10554 10554 NAILING FLANGE
17 P253 P253 P253 P253 FITTING, ORIFICE ANGLED
18a P209 - P209 - ORIFICE #31 (NAT)
18b - P245 - P245 ORIFICE #50 (LP)
19a - R5675 - R5675
AIR SHUTTER-FULLY OPEN
(LP ONLY)
19b R5676 - R5676 - AIR SHUTTER (NAT UNITS)
20a - R3623 - R3623 PILOT ASSEMBLY LP
20b R3624 - R3624 - PILOT ASSEMBLY NAT
21 24756 24515 24756 24515
BURNER SUB ASSEMBLY
(INCLUDES #22)
22 R5677 R9692 R5677 R9692 TUBE, VENTURI ASSEMBLY
23 24119 24119 24119 24119 BURNER BASE
24 24143 24143 24143 24143 BURNER SUPPORT
25 24144 24144 24144 24144 GRATE ASSEMBLY
26 24146 24146 24146 24146 TUBING ASSEMBLY, INLET
27 N/A 24147 N/A 24147
TUBING ASSEMBLY, PILOT
(LP ONLY)
28 R2423 R2423 R2423 R2423
CONNECTOR, MALE
5/16 X 3/8 NPT
29 20115 20115 20115 20115 VALVE BRACKET
30a - R3625 - R3625 VALVE, LPG
30b R3626 - R3626 - VALVE, NAT
