58
Menu List
8. System
Parameters Explanation Values
1: System Frame Rate Switches between NTSC and PAL 60-NTSC, 50-PAL
2: SD Deinterlacer SD section I/P conversion function Off, On
3: SD Input Sync Threshold SD input sync level adjustment -48–+79
4: REMOTE Baudrate REMOTE bit rate setting 9600bps, 19200bps
5: Seamless Delay Time Delay time when channel select buttons are used 0–50 (Field)
6: HD/RGB On Screen Display Displays HD/RGB PGM/PREVIEW output in menu Off, On
7: Panel Operation Mode Sets the mode used for switching the video Direct Mode, Preset Mode
8: Input Sw LED Color Sets the colors of the channel select button indicators Main=YEL : Sub=GRN
Main=YEL : Sub=RED
Main=RED : Sub=GRN
Main=RED : Sub=YEL
Main=GRN : Sub=RED
Main=GRN : Sub=YEL
9: All Data Transmit Transmits the V-44SW’s settings from the REMOTE
connector. --- (Procedure:
☞
p. 49)
10: System Reset The sub-menu settings are returned to their factory default
settings --- (Procedure:
☞
p. 29)
11: Memory Protect Menu settings protect function Off, On
12: V-440HD Slave Mode Switches V-440HD Slave Mode on and off Off, On
9. MIDI Setup
Parameters Explanation Values
1: MIDI Sw Mode [MIDI] button function MIDI In/Out Sw, V-LINK Indicator
2: MIDI Tx Channel Sets MIDI Transmit channel 1–16
3: MIDI Rx Channel Sets MIDI Receive channel 1–16, Off
4: MIDI Out/Thru Switch MIDI OUT/THRU connector function Out, Thru
5: V-LINK Switch Switches the V-LINK Slave function on and off Off, On
6: Device ID Device ID setting 00H–1FH
7: Panel Preset Tx Type PANEL PRESET (p. 42) transfer method Settings, Number Only
8: Take Switch Assign [TAKE] button MIDI assign Off, CC#01–CC#95, ChAftTt, PitchBD
9: Transition Assign TRANSITION button MIDI assign Off, CC#01–CC#95, ChAftTt, PitchBD
10: Transition Time [TRANSITION TIME] knob MIDI assign Off, CC#01–CC#95, ChAftTt, PitchBD
11: Video Fader Assign Internal video fader MIDI assign Off, CC#01–CC#95, ChAftTt, PitchBD
12: Key Sw Assign [KEY] button MIDI assign Off, CC#01–CC#95, ChAftTt, PitchBD
13: P in P Sw Assign [P in P] button MIDI assign Off, CC#01–CC#95, ChAftTt, PitchBD
14: Panel Preset Sw Assign PANEL PRESET button MIDI assign Off, CC#01–CC#95, ChAftTt, PitchBD
15: Output Format Sw Assign OUTPUT FORMAT button MIDI assign Off, CC#01–CC#95, ChAftTt, PitchBD
16: Fade Sw Assign [OUTPUT FADE] button MIDI assign Off, CC#01–CC#95, ChAftTt, PitchBD
17: Fade Level Assign [TIME] knob MIDI assign Off, CC#01–CC#95, ChAftTt, PitchBD
18: MIDI Bulk Dump Transmits the settings to MIDI-connected devices --- (Procedure:
☞
p. 47)
19: MIDI Reset The sub-menu settings are returned to their
factory default settings --- (Procedure:
☞
p. 29)
The V-44SW’s system settings are made here.
MIDI-related settings are made here.
