14
Setup and Settings Guide
● Whenever connecting the V-44SW to other devices, always turn off the power to all devices to prevent malfunction and/
or damage to video monitors and other equipment.
● Be sure to use cables and adapter plugs with the proper connectors matching those of the other devices you are using.
● Refer to “Examples for Connecting and Setting the V-44SW” (p. 18).
Device Connections
Composite
output connector VGA output connector VGA input connector HD input connector S-Video output
connector
S-Video
cable
Composite
cable
D-sub-5BNC cable
D-sub-5BNC
cable
D-sub-5BNC
cable
Composite cable
VGA cable
VGA cable
Ground
terminal
D-sub-5BNC cable
VGA cable
HD output connector
VGA cable
Final Output (RGB)
V-44SW Rear Panel
To power outlet
Projector or Other Display
Final Output (HD)
PC or Other Device
RGB Video Output Device
HD Camera
or Other Device
HD Video Output Device SD Video Output Device
DV Camera, Player,
or Other Device
Powe cord
VGA input connector
Multiformat Monitor
or Other Display
VGA Display
or Other Display
HD input connector VGA input connector HD input connector
Multiformat Monitor
or Other Device
VGA Display
or Other Device
VGA Monitor SD IN Monitor
TV Monitor
or Other Device
TV Monitor
or Other Device
HD IN Monitor Preview Monitor
Preview Monitor
S-Video input connector Composite input connecto
Menu Display Monitor
Plasma Display
or Other Display
