Eton E1 - Manual (Page 17)

33
XM OPTION DISPLAY DESCRIPTION continued
E1 MANUAL
The second press causes only two channels at a time
to be displayed, but the channel name, artist, and title
will be displayed. The third press will cause the display
items (Described in 6, 7, 8, & 9) to disappear, and the
‘TUNING’ knob will have no affect. The fourth press
will cause the display to return to its original display
condition but will leave the receiver in the XM-ALL
mode. When in the XM-ALL mode, “XM-ALL” will be
shown in reverse video as shown here.
23. SW / MW / LW - Pressing this softkey will exit the
XM mode and return the receiver to the Shortwave,
AM Broadcast , or Long Wave bands. Which of these
bands will become active is determined by which one
of them was selected last before XM mode was select-
ed.
24. FM / XM - Pressing this softkey will return the
receiver to the FM broadcast band.
25. LOCK - This indicator appears when the
‘CLEAR/LOCK’ is pressed for 3 seconds. When this indi-
cator is visible, all front panel controls are disabled
except ‘CLEAR/LOCK’, and the ‘VOLUME, TREBLE, and
BASS knobs. To remove the ‘ ’ LOCK indicator and re-
enable the disabled controls, press the ‘CLEAR/LOCK’
key again for 3 seconds.
26. TIMER 1 2 - When this indicator is present, it
shows that timer 1 and 2 are enabled. Timer operation
is covered in detail on starting page52.
27. CLOCK - This item displays the Local or GMT time.
The clock is covered in detail starting on page 52.
28. TERR - This indicator shows the relative signal
strength of a nearby terrestrial repeater retransmitting
the XM signal.
29. SAT - This indicator shows the relative signal
strength from the stronger of the two satellites (Rock
or Roll) supplying the XM Radio signal.
32
‘FAVORITES A’ selections one at time, and will then
scroll through the ten ‘FAVORITES B’ selections.
Continued rotation of the ‘TUNING’ knob will cause
continued scrolling through first ‘FAVORITES A’ and
then ‘FAVORITES B’ memory locations. Using the ‘<
SELECT >’ softkey will scroll through the ‘FAV A’ and
then ‘FAVORITES B lists five at a time.
12. FAVORITE LISTS B - Pressing the ‘B’ softkey will
call up the first five selections in the ‘FAVORITES B’ list.
Repeatedly pressing the ‘B’ softkey will toggle back
and forth between the first and last five ‘B’ list selec-
tions. The ‘TUNING’ knob will scroll through the ten
‘FAVORITES B’ selections one at time, and will then
scroll through the ten ‘FAVORITES A’ selections.
Continued rotation of the ‘TUNING’ knob will cause
continued scrolling through first ‘FAVORITES B’ and
then ‘FAVORITES A’ memory locations. Using the ‘<
SELECT >’ key will scroll through the ‘FAVORITES B’
and then ‘FAVORITES A lists five at a time.
13. CHAN - Pressing the CHAN softkey causes the
displayed channel information (described in 8 & 9) to
show the name of the channel.
14. ARTIST - Pressing the ‘ARTIST’ softkey causes the
displayed channel information (described in 8 & 9) to
display the name of the artist currently performing on
that channel.
15. TITLE - Pressing the ‘TITLE’ softkey causes the dis-
played channel information (described in 8 & 9) to dis-
play the name of the selection being played.
16. SCAN - Pressing the ‘SCAN’ will cause the receiv-
er to scan through each XM channel within the current
XM mode (i.e.:CATEGORY, FAVORITES, or XM-ALL), one
channel at a time stopping approximately 3 seconds
on each channel. Pressing ‘SCAN’ again will stop the
scan.
17. ENTER - Pressing the ‘ENTER’ softkey will cause
any channel entry made by pressing the appropriate
‘Direct-Key-Input’ key, turning the “TUNING’ knob, or
pressing the ‘’ keys to occur immediately.
Otherwise, there can be a delay of from 1 to 9 sec-
onds, depending upon the parameters entered in item
2 (Auto Enter OFF / ON) and item 3 (Auto Enter Delay)
of the “XM” menu. If Auto Enter is OFF, (“XM” menu
item 2) no channel change will occur until ‘ENTER’ is
pressed.18. TUN LOCK - “TUN LOCK” will appear if the ‘FAST
/ TUNING LOCK’, or the ‘CLEAR/LOCK’ keys have beenXM OPTION DISPLAY DESCRIPTION continuedpressed for approximately 3 seconds. When this indica-
tor is visible, the ‘TUNING’ knob will have no affect. To
release the ‘TUNING’ knob and clear the “TUN LOCK”
indicator, press the ‘FAST / TUNING LOCK’ key again
for approximately 3 seconds if this indicator appears
alone. If it appears in combination with the “LOCK”
indication, press the ‘CLEAR/LOCK’ key for 3 seconds
to release.19. LAST - Pressing the ‘LAST’ softkey will recall the
previously received XM channel.20. FAVORITES - Pressing the ‘FAVORITES’ softkey
once will switch the receiver to the FAVORITES mode.
In this mode, the ‘TUNING’ knob will scroll through the
selections programmed into FAVORITE lists “A” and
“B” one at a time, and the ‘< SELECT>’ keys will scroll
through these lists 6 at a time. The second press will
cause only two of the “favorites” selections at a time
to be displayed, but each selection will show the chan-
nel name, the artist, and the title. The third press will
cause the display items (Described in 6, 7, 8, & 9) to
disappear, and the ‘TUNING’ knob will have no affect.
The fourth press will cause the display to return to its
original display condition but will leave the receiver in
the FAVORITES mode. When in the FAVORITES mode,
either by pressing the ‘FAVORITES’ softkey or by press-
ing the ‘A’ or ‘B’ softkeys, “FAVORITES” will be shown
in reverse video as shown here. If no selection is made,
the FAVORITE mode will time out and revert to XM-
ALL mode.21. CATEGORY - Pressing this softkey once causes
the receiver to go to category mode. When in this
mode the ‘< SELECT >’ keys will scroll through each
category, and the ‘TUNING’ knob will scroll through
each channel in a given category. The second press
causes only two channels at a time to be displayed,
but the channel name, artist, and title will be dis-
played. The third press will cause the display items
(Described in 6 and 7) to disappear. The fourth press
will cause the display to return to its original display
condition but will leave the receiver in the CATEGORY
mode. When in the CATEGORY mode, “CATEGORY”
will be shown in reverse video as shown here. If no
selection is made, the receiver will revert to XM-ALL
mode.22. XM-ALL - When the ‘XM-ALL’ softkey is pressed
once, the ‘TUNING’ knob will scroll through all avail-
able XM channels one channel at a time, and the ‘<
SELECT >’ keys will scroll through all available chan-
nels six at a time. Pages: 1 … 15 16 17 18 19 … 40 wrong Brand wrong Model non readable See also other documents in the category Eton Cars: E1 (35 pages) VECTOR 250R (32 pages) Sitemap
18. TUN LOCK - “TUN LOCK” will appear if the ‘FAST
/ TUNING LOCK’, or the ‘CLEAR/LOCK’ keys have been
XM OPTION DISPLAY DESCRIPTION continued
pressed for approximately 3 seconds. When this indica-
tor is visible, the ‘TUNING’ knob will have no affect. To
release the ‘TUNING’ knob and clear the “TUN LOCK”
indicator, press the ‘FAST / TUNING LOCK’ key again
for approximately 3 seconds if this indicator appears
alone. If it appears in combination with the “LOCK”
indication, press the ‘CLEAR/LOCK’ key for 3 seconds
to release.
19. LAST - Pressing the ‘LAST’ softkey will recall the
previously received XM channel.
20. FAVORITES - Pressing the ‘FAVORITES’ softkey
once will switch the receiver to the FAVORITES mode.
In this mode, the ‘TUNING’ knob will scroll through the
selections programmed into FAVORITE lists “A” and
“B” one at a time, and the ‘< SELECT>’ keys will scroll
through these lists 6 at a time. The second press will
cause only two of the “favorites” selections at a time
to be displayed, but each selection will show the chan-
nel name, the artist, and the title. The third press will
cause the display items (Described in 6, 7, 8, & 9) to
disappear, and the ‘TUNING’ knob will have no affect.
The fourth press will cause the display to return to its
original display condition but will leave the receiver in
the FAVORITES mode. When in the FAVORITES mode,
either by pressing the ‘FAVORITES’ softkey or by press-
ing the ‘A’ or ‘B’ softkeys, “FAVORITES” will be shown
in reverse video as shown here. If no selection is made,
the FAVORITE mode will time out and revert to XM-
ALL mode.
21. CATEGORY - Pressing this softkey once causes
the receiver to go to category mode. When in this
mode the ‘< SELECT >’ keys will scroll through each
category, and the ‘TUNING’ knob will scroll through
each channel in a given category. The second press
causes only two channels at a time to be displayed,
but the channel name, artist, and title will be dis-
played. The third press will cause the display items
(Described in 6 and 7) to disappear. The fourth press
will cause the display to return to its original display
condition but will leave the receiver in the CATEGORY
mode. When in the CATEGORY mode, “CATEGORY”
will be shown in reverse video as shown here. If no
selection is made, the receiver will revert to XM-ALL
mode.
22. XM-ALL - When the ‘XM-ALL’ softkey is pressed
once, the ‘TUNING’ knob will scroll through all avail-
able XM channels one channel at a time, and the ‘<
SELECT >’ keys will scroll through all available chan-
nels six at a time.
