6-20
Maintenance
Date en cours : 12 juillet 2004
\\Sct01002\Be31-doc\DOC 31 - En cours\Travaux en cours\Fax\MFL V 2\LU 251 524 337A MFL_V2 LASER PRO 346_348 GB\Maintenance
Gb.fm
Between the drum cartridge and the fusing unit
Remark : Do not touch the image transfer roller (black roller at the bottom of the printer).
Reinstall the drum cartridge and the toner cartridge (refer to paragraph Replacing cartridges,
page 6-2)
Close the upper cover and press it down gently but firmly until it locks into place
