Connecting and Printing
12 OPERATION GUIDE
Connecting the Parallel Cable
1 Connect the printer cable (not
included) to the Parallel Interface
Connector.
NOTE: Use a parallel printer cable that complies with IEEE 1284
standards. For optimum performance, install the printer close to the
computer. The connection cable should be shielded and no longer than 3
meters long.
2 Close the clips on both sides to fix the connector in place.
3 Connect the other end of the printer cable to the computer’s parallel
interface connector.
Connecting the Power Cord
Install the printer close to an AC wall outlet. If an extension cord is used,
the total length of the power cord plus extension should be 5 meters (16
feet) or less.
NOTE: Ensure the printer’s power switch is off. Only use the power cord
supplied with the printer.
1 Connect the power cord to the
Power Cord Connector at the rear
of the printer.
2 Connect the other end of the power cord to a power outlet.
