MSO4000/DS4000 Quick Guide
21
12. Trigger Level/threshold
The trigger level label
will be displayed at the right of the screen
when the trigger source is selected CH1 to CH4 and the trigger level
value is displayed at the upper-right corner of the screen. Note: in runt
trigger and slope trigger, there are two trigger level labels ( and
).
When Using TRIGGER
LEVEL to modify the trigger level, the
trigger level value will change with the up and down of
.
There is no trigger level label
displayed when the trigger source is
selected D0 to D15 and the trigger threshold is displayed at the
upper-right corner of the screen (only available for MSO4000 series
digital oscilloscope.).
13. CH1 Vertical Scale
Display the voltage value per grid of CH1 waveform vertically.
Use VIRTICAL
SCALE to modify this parameter.
The following labels will be provided according to the current channel
setting: channel coupling (e.g. in AC coupling), bandwidth limit (e.g.
when bandwidth limit is enabled) and input impedance (e.g.
when the input impedance is 50Ω).
14. CH2 Vertical Scale
Display the voltage value per grid of CH2 waveform vertically.
Use VIRTICAL
SCALE to modify this parameter.
The following labels will be provided according to the current channel
setting: channel coupling (e.g. in AC coupling), bandwidth limit (e.g.
when bandwidth limit is enabled) and input impedance (e.g.
when the input impedance is 50Ω).
15. CH3 Vertical Scale
Display the voltage value per grid of CH3 waveform vertically.
Use VIRTICAL
SCALE to modify this parameter.
The following labels will be provided according to the current channel
setting: channel coupling (e.g. in AC coupling), bandwidth limit (e.g.
when bandwidth limit is enabled) and input impedance (e.g.
when the input impedance is 50Ω).
16. CH4 Vertical Scale
Display the voltage value per grid of CH4 waveform vertically.
Use VIRTICAL
SCALE to modify this parameter.
The following labels will be provided according to the current channel
