MSO4000/DS4000 Quick Guide 20
The logic high levels of the digital waveforms are displayed in blue, the logic
low levels are displayed in green which complies with the color of the digital
channel label and the edges are displayed in white. Both the label and the
waveform of the digital channel currently selected are displayed in red.
Note: this function is only available for MSO4000 series digital oscilloscope.
4. Status
Available states include RUN, STOP, T’D (triggered), WAIT and AUTO.
5. Horizontal Time Base
 Represent the time per grid on the horizontal axis on the screen.
 Use HORIZONTAL
SCALE to modify this parameter. The range
available is from 1.000 ns to 1000 s.
6. Sample Rate/Memory Depth
 Display the current sample rate and memory depth of the oscilloscope.
 Use HORIZONTAL
SCALE to modify this parameter.
7. Waveform Memory
Provide the schematic diagram of the memory position of the waveform
currently on the screen.
8. Trigger Position
Display the trigger position of the waveform in the waveform memory and
on the screen.
9. Horizontal Position
Use HORIZONTAL POSITION to modify this parameter. Press down
the knob to automatically set the parameter to zero.
10. Trigger Type
Display the currently selected trigger type and trigger condition setting.
Different labels are displayed when different trigger types are selected.
For example: represents triggering on the rising edge in “Edge” trigger.
11. Trigger Source
Display the trigger source (CH1-CH4, EXT, EXT/5, AC Line or D0-D15)
currently selected. Different labels are displayed when different trigger
sources are selected and the color of the trigger parameter area will change
accordingly.
For example: denotes that CH1 is selected as the trigger source.
waveform on the
screen
