MSO4000/DS4000 Quick Guide
19
User Interface
MSO4000/DS4000 oscilloscope provides 9 inches, WVGA (800*480) 160,000 color
TFT LCD. What is worth mentioning is that the 14-grid ultra-wide screen makes you
view “longer” waveform.
Figure 13 User Interface
1. Measurement Menu
Provide 12 horizontal (HORIZONTAL) and 12 vertical (VERTICAL)
measurement parameters. Press the softkey at the left of the screen to
activate corresponding measurement item.
2. Analog Channel Label/Waveform
Different channels are marked by different colors and the color of the
waveform complies with the color of the channel.
3. Digital Channel Label/Waveform
13 14 15 16 17 18 19 20
1 2 3 4 5 6 7 8 9 10 11 12
