Riello UPS Sentinel Dual (High Power) (3.3 - 10 kVA) - Manual (Page 68)

68
T
ECHNICAL DATA TABLE
MODELS SDL 5000 SDL 6000
INPUT
Nominal voltage [Vac] 220 - 230 - 240
Nominal frequency [Hz] 50 – 60
Accepted range [Vac] 0 ÷ 276
Voltage and frequency range for non
intervention of the battery [Vac]
[Vac]
[Vac]
[Hz]
Maximum: 276
Minimum: 164 ÷ 84
(from 100% to 50% of load in
linear mode)
Return to mains-powered operation: 180
Frequency: 40 ÷ 72
Maximum current (1) [A] 25 30
Nominal current
(2)
[A] 18 22
Power factor 0.98
Current distortion @ maximum load 6%
BYPASS
Accepted voltage range for switching [Vac] 180 ÷ 264
Accepted frequency range for switching Frequency selected ±5 %
Switching time [msec] 0,1
BATTERY
No. batteries / V / Ah 16 / 12 / 7 high rate discharge
Recharge time (8) [h] 4 ÷ 6
OUTPUT
Nominal voltage
(7)
[Vac] 220 / 230 / 240 ±1.5%
Maximum current [A] 23 / 22 / 21 27 / 26 / 25
Static variation
(3)
1.5%
Dynamic variation (4)
5% in 20 msec
Waveform Sinusoidal
Voltage distortion @ linear load 3%
Voltage distortion @ distorting load 5%
Frequency (5) 50 or 60 Hz selectable
Current crest factor 3 : 1
Nominal power [VA] 5000 6000
Nominal power [W] 3500 4200
MISCELLANEOUS
Leakage current to earth [mA] 2
AC/AC efficiency > 91%
Ambient temperature (6) [°C] 0 – 40
Humidity < 90% non-condensing
Protections Excessive battery discharge – Overcurrent – short-circuit –
Overvoltage – undervoltage - thermal
Hold-up time [msec] 35
Noise level < 45 dB(A) at 1 mt.
Dimensions H x L x D [mm] 455 x 175 x 660 (9)
Weight [Kg] 64
