46
P
RESENTATION
The new Sentinel Dual UPS family has been designed with a special eye to versatility. These UPSs can in fact
be installed either in a tower version or in a rack version, according to requirements. The 2 different versions of
the product are shown below:
The UPS is also provided with two dedicated battery packs that allow the easy hot swap replacement of the
batteries in full safety thanks to the protected connection system.
SDL 5000 SDL 6000
Nominal power [VA] 5000 6000
Nominal voltage [Vac] 220 / 230 / 240
Dimensions H x L x D [mm] 455 x 175 x 660 (1)
Weight [Kg] 64
(1)
The H dimension is different in the rack version with handles mounted: 483mm x 175mm x 660mm (H x L x D)
Note: 175mm = 4U
483mm = 19”
Tower Rack
