Ear view – Riello UPS Sentinel Dual (Low Power) (1000 - 3000 VA) User Manual
Page 7
R
EAR VIEW
7
Model 2200VA / 3000VA
Model 1000VA / 1500VA
Communication port RS232
Battery expansion connector (optional)
USB communication port
IEC 10A output socket
IEC 16A output socket
IEC 16A input plug
Communication Card Slots
IEC 10A input plug
Cooling fans
Circuit breaker
Remote control terminal board
