T
OWER VERSION
T
his chapter describes the steps for preparing the UPS and battery box for tower version use.
ATTENTION:
For your safety and that of the product, you must carefully follow the instructions given here below.
BEFORE YOU CARRY OUT THE FOLLOWING SEQUENCE OF OPERATIONS, MAKE SURE THAT
THE UPS IS COMPLETELY SWITCHED OFF AND NOT CONNECTED TO THE MAINS POWER
SUPPLY OR TO ANY LOAD
the tower configuration.
Once removed from the packaging, the UPS is already preset for installation in
o complete the configuration, simply mount the UPS on the two support feet.
T
Each leg consists of two parts, connecting to each other at joints. To put a leg together proceed as shown in the
figure.
Assemble two legs and secure the UPS on top of them as shown in the figure below.
