RISCO Group VUpoint Bullet Outdoor IP Camera RVCM52E User Manual
Page 16
16
NOTE: By default the TCP/IP settings should already be defined.
5. Click Save to save the changes.
6. Select Connection. The Connection Parameters page is displayed.
Figure 18 Connection Parameters
7. Set the following port connection parameters of the camera:
TCP Port
Set the TCP port you want to define for the camera (in our
example 47777).
UDP Port
Set the UDP port (in our example 47778)
HTTP Port
The default port number is 80, and can be changed to any
port range 1024 to 65535 (in our example 10080).
RTSP Port:
The default port number is 554 (in our example 47554).
HTTPS Port
The default port number is 443, and can be changed to any
port range 1024 to 65535 (in our example 47443).
8. Click Save to save the changes.
9. Repeat the above steps for each camera using the relevant IP address and
alternative port number for each.
