Pro-Flo EFI Installation Instructions
©2005 Edelbrock Corporation
Rev. 2/05
Brochure #63-0273
Catalog #3530 & #3531
The Coolant Temperature sensor attaches to the
main harness.
The Manifold Absolute Pressure sensor
attaches to the main harness.
The Manifold Air Temperature sensor attaches to the
main harness.
Only the fuel injector connectors are identical, but
they are placed in logical sequence. Refer to the
diagram when installing the harness connectors to
the fuel injectors.
