Page 20

- 20 -

WB CONTROL: ATW

ATW (Auto Tracking White Balance): This mode can be used within the color
temperature range from 2,500°K to 9,500°K (eg, fluorescent light, outdoor,
sodium vapor lamp or inside tunnels).

WB CONTROL: MANUAL

KELVIN: value ranges from 2500 to 9500. You could adjust White Balance
manually according to environment’s color temperature.

PREVIOUS PAGE: Press SET button and you can return to the previous page.

4. 5 AGC

ON/OFF

AGC: ON. By selecting ON, you can activate automatic gain control feature.

AGC MENU: SET LEVEL from MIN 0 to MAX 36.

PREVIOUS PAGE: Press SET button and you can return to the previous page.
AGC:OFF. It is a fixed gain adjustment.

AGC MENU

>SET LEVEL ++++++++++++

MIN 32 MAX

PREVIOUS PAGE.

KELVIN

>VALUE ++++++++++++

2500 4500 9500

PREVIOUS PAGE.

MAIN MENU

SETUP ID..

LENS DC..

WDR..

>WB CONTROL MANUAL

AGC ON

LOW LIGHT SLOW-SH..

SYNC ..

DAY/NIGHT

EXIT MENU
