2.4 Adjust Lens zoom and focus and View
a. Adjust Lens zoom and focus(for vari-focal lens models)
b. Adjust view angle
The camera can be rotated 360° horizontally, 140° vertically and 60°
3’rd axis view angles (as shown in Figure 11). Adjust the proper
camera view angle as needed.
Figure 11
Lens fixing Screws
140°
360
°
60°
Zoom
Focus
Figure 10
