- 10 -

d. Tighten fixing screws and finished

2.2 Mounting Cameras on the Ceiling/Wall

a. Mount the base to the wall or ceiling, fix the base by the 4 screws in the

accessory pack.(see dimension b for drilling dimension). This dome is
weighted 1.7kg, please make sure if the mounting is strengthened enough to
support it, if not, please reinforce the mounting according to the
environment. See figure 4.

Back conduit hole

Mounting Setscrew

Figure 4

Figure 3-4
