- 11 -
b. Take off cable conduit if you need to wire cable through side conduit hole. The
camera comes with a conduit plug pre-installed in the PF 1/2 conduit hole on the side.
The conduit plug can be removed and installed in the back conduit hole (as shown in
Figure 5)
2.3 Conduit cable and Connect Power and Video
a. If you want to wire cable through side conduit hole. Find the water-proof
conduit in the bag and wire power connection cable through it.
Caution: When used in the environment with
high humidity, apply an appropriate gasket or
sealant around the conduit connection.
Side conduit hole (PF1/2)
Conduit plug
Back conduit hole
Figure 5
Figure 6-1
Figure 6-2
