Displaying VLAN Settings
Summit 300-48 Switch Software User Guide 71
VLAN Configuration Examples
The following Summit 300-48 switch example creates a tag-based VLAN named video. It assigns the
VLANid 1000. Ports 1:4 through 1:8 are added as tagged ports to the VLAN.
create vlan video
config video tag 1000
config video add port 1:4-1:8 tagged
The following Summit 300-48 switch example creates a VLAN named sales, with the VLANid 120. The
VLAN uses both tagged and untagged ports. Ports 1:1 through 1:3 are tagged, and ports 1:4 and 1:7 are
untagged. Note that when not explicitly specified, ports are added as untagged.
create vlan sales
config sales tag 120
config sales add port 1:1-1:3 tagged
config sales add port 1:4,1:7
Displaying VLAN Settings
To display VLAN settings, use the following command:
show vlan {} {detail}
The show command displays summary information about each VLAN, which includes:
• Name
• VLANid
• How the VLAN was created
• IP address
• STPD information
• QoS profile information
• Ports assigned
• Tagged/untagged status for each port
• How the ports were added to the VLAN
• Number of VLANs configured on the switch
Use the detail option to display the detailed format.
delete vlan Removes a VLAN.
unconfig ports monitor vlan Removes port-based VLAN monitoring.
unconfig vlan ipaddress Resets the IP address of the VLAN.
Table 18: VLAN Configuration Commands (continued)
Command Description
