Summit 300-48 Switch Software User Guide 11
Figures
1 Example of a port-based VLAN on the Summit 300-48 switch 64
2 Single port-based VLAN spanning two switches 65
3 Two port-based VLANs spanning two switches 66
4 Physical diagram of tagged and untagged traffic 68
5 Logical diagram of tagged and untagged traffic 68
6 Sample integrated wired and wireless network 74
7 Permit-established access list example topology 116
8 Access control list denies all TCP and UDP traffic 117
9 Access list allows TCP traffic 118
10 Host A initiates a TCP session to host B 118
11 Permit-established access list filters out SYN packet to destination 119
12 ICMP packets are filtered out 119
13 Ethernet packet encapsulation 126
14 IP packet header encapsulation 128
15 Multiple Spanning Tree Domains 147
16 Tag-based STP configuration 148
17 Routing between VLANs 154
18 Unicast routing configuration example 162
