Site Requirements
1-2 Preparing for Installation
Table 1-1: Specifications
Parameter Description
Dimensions:
(Length x Weight x Height) 6.2" x 3.9" x 1.0"
Input voltage 5.2 VDC
Input current 120 mA (excluding radio card)
Temperature 0
°
C to 55
°
C
Relative Humidity 0% to 90% (non-condensing)
Radio Interface RoamAbout 802.11 PC Card
Ethernet Interface RJ45 10BaseT (swapped to allow the use of a
straight through cable when connected to a
computer)
Serial Interface (optional) • Data rates: 112 to 115K Baud
• Data format: 7, 8 Data; 1, 2 Stop;
ENO Parity
• Control lines: RTS, CTS, DSR, DTR, RI.
CD @ RS232 Levels
• Connector: Female DB9; Pinout:
— 1 - R1 (input)
— 2 - TX
— 3 - RX
— 4 - DTR
— 5 - GND
— 6 - DSR
— 7 - RTS
— 8 - CTS
— 9 - CD (input)
