DFE-Gold Module
1-4 Introduction
Figure 1-1 4H4285-49 DFE-Gold Module
1 OFFLINE/RESET button 7 GROUP status LEDs
2 RJ45 COM (Console Port) 8 GROUP select LEDs
3 MGMT LED 9 NEM option slot
4 CPU LED 10 48 Vdc/20 Amperes Maximum, optional power input connector
5 POE LED 11 Ports (1-48), 10/100 Mbps through RJ45 connectors
6 GROUP SELECT button
