48
GB
Assembling the Grass Box
D
. 1.. Connect.the.two.pieces.of.the.
. . collection.box.(16).
. 2.. Connect.the.handle.(15).in.one.
of.the.two.pieces.of.the.collec-
tion.box.(16).
. Do.not.work.with.the.lawn.mower.
without.impact.protection..There.is.
a.risk.of.injury.
. We.recommend.always.using.the.
grass.box.when.working.with.the.
lawn.mower,.otherwise.the.mow-
ing.result.may.be.significantly.im-
paired.
Operation
Hanging On / Removing the
Grass Box
E
.1.. To.hang.on.the.grass.box.(4),.
lift.the.collision.guard.(7).and.
hang.on.the.grass.box..Fold.the.
collision.guard.(7).onto.the.grass.
box.(4)..It.holds.the.grass.box.in.
the.correct.position.
. 2.. To.remove.the.grass.box.(4),.
lift.the.collision.guard.(7).and.
detach.the.grass.box..Fold.the.
collision.guard.(7).back.onto.the.
mower.housing.(6)..
Adjusting the Cut Height
. Switch.off.the.equipment,.discon-
nect.the.plug.and.wait.for.the.blade.
to.stop..There.is.a.risk.of.injury.
The.lawn.mower.can.be.set.to.the.follow-
ing.cut.heights.by.means.of.three.position.
changes.of.the.front.and.rear.wheels,.ad-
justing.the.individual.wheels:
cable.from.heat,.oil.and.sharp.edges.
•. Switch.off.the.equipment.and.discon-
nect.the.plug.from.the.socket.if.the.
power.cable.is.damaged..If.the.power.
cable.for.this.equipment.is.damaged,.
it.must.be.replaced.with.a.special.
power.cable,.which.is.available.from.
the.manufacturer.or.a.customer.service.
agent.of.the.same.
•. Do.not.connect.a.damaged.power.
cable.to.the.mains..Do.not.touch.a.
damaged.power.cable.when.it.is.
connected.to.the.mains..A.damaged.
power.cable.may.result.in.contact.with.
live.parts.
Assembly
. Disconnect.the.plug.before.any.
work.on.the.equipment..There.is.a.
risk.of.injury.
Assembling the Curved Han-
dle
B .1.. Insert.the.lower.bar.(3).into.the.
slot.on.the.lawnmower.housing.
(6).
. 2.. Fix.the.bar.(3).using.the.en-
closed.screws.(13).
C
.3.. Screw.all.four.wheels.(5).onto.
the.lawn.mower.housing.(6)..All.
of.the.wheels.must.be.set.to.the.
same.height.
. 4.. Fix.the.curved.handle.(1).using.
the.enclosed.screws.(14).and.the.
wing.nuts.(2).on.the.lower.bar.
(3)..There.are.two.possible.posi-
tions.
. 5.. Clip.the.cable.holder.(8).into.the.
bar.(3).and.thus.fix.the.cable.
. When.both.wing.nuts.are.loosened,.
the.curved.handle.can.be.folded.
down.for.storing.the.equipment..
Ensure.that.the.power.cable.is.not.
caught.
